Handrail Joiner Description
The Dome Rail Slot Tube 90 Degree Joiner Vertical is designed to connect two sections of round-shaped railing together at a 90-degree angle. It is suitable to fit a Φ50.8mm (approximately 2 inch) railing, slotted elbow joint for a 90-degree vertical connection, and provides for easy installation and adjustment.
The Slot Tube 90º Joiner is made of high-quality stainless steel for durability and corrosion, making it suitable for both indoor and outdoor use. These handrail fittings are used to residential railings for balconies, decks, and staircases, orcommercial railings for buildings, public spaces, and industrial facilities.
Handrail Joiner Specifications
|
Product Name |
Slot Tube 90º Joiner Vertical |
|
Coupling |
50.8mm*1.5mm |
|
Weight |
0.31Kg |
|
Finish |
Classic Satin/Mirror |
|
Material |
Duplex stainless steel 2205, Stainless steel 304/316 |
|
Application |
Handrail fence for various scenes, etc. |
|
Casting Process |
Silica Sol Technics with Lost-wax Process |
|
Certifications |
Australian Standard Test/Patent Certificate/IATF16949/ISO9001/ISO14001/TUV/PED/AD2000 |
|
OEM |
Available |
|
Annual Output |
2000MT |
|
Tooling Leadtime |
2--4 Weeks |
|
Delivery Time |
4--5 Weeks |
Package Specification
Plastic Bag, Bubble Bag.
Paper Carton, Wooden Case, or as Required.
Note
These slot tube joiners are available in different finishes (polished, satin) to suit various environmental requirements. They are designed to accommodate variations in railing angles, offers flexibility in railing alignment, and ensure the stability and safety of the railing system.
