Handrail Joiner Description
The Stainless Steel Round Rail Left & Right Adjustable Elbow Joiner is designed to connect two sections of round-shaped railing together at a 90-degree angle. The unique feature of this joiner is its slotted design, which allows for easy adjustment of the railing angle. Its round top to fit a Φ50.8mm (approximately 2 inch) railing, elbow joint for a 90-degree connection.
The round rail adjustable stainless steel elbow joiner is made of grade 304/316/2205 for its durability, corrosion resistance, and aesthetic appeal, making it suitable for both indoor and outdoor use. These handrail fittings are used to residential railings for staircases, commercial railings for buildings and public spaces.
Handrail Joiner Specifications
|
Product Name |
Round Rail Left & Right Adjustable Elbow Joiner |
|
Coupling |
Φ50.8mm |
|
Weight |
0.50Kg |
|
Finish |
Classic Satin/Mirror |
|
Material |
Duplex stainless steel 2205, Stainless steel 304/316 |
|
Application |
Handrail fence for various scenes, etc. |
|
Casting Process |
Silica Sol Technics with Lost-wax Process |
|
Certifications |
Australian Standard Test/Patent Certificate/IATF16949/ISO9001/ISO14001/TUV/PED/AD2000 |
|
OEM |
Available |
|
Annual Output |
2000MT |
|
Tooling Leadtime |
2--4 Weeks |
|
Delivery Time |
4--5 Weeks |
Package Specification
Plastic Bag, Bubble Bag.
Paper Carton, Wooden Case, or as Required.
Note
These round rail adjustable stainless steel elbow joiners are available in different finishes (polished, satin) to suit various environmental requirements. They are designed for provides for easy installation and adjustment, and provide a clean, safe, and attractive appearance for the stair railing system.
