Handrail Joiner Description
The Square Top Rail Vertical Adjustable Connector Right is used to connect two sections of square-shaped railing together at a vertical angle. This vertical adjustable handrail connector is designed for a right-hand corner connection, square top to fit a 25mm x 21mm railing, accommodate variations in railing wall angles, and ensure the stability and safety of the railing system.
These handrail fittings are made of stainless steel for durability and corrosion resistance. The connector is available in different finishes such as classic satin, transparent satin, mirror, and powder coat matte black.
Handrail Joiner Specifications
|
Product Name |
Square Top Rail Vertical Adjustable Connector-Right |
|
Coupling |
21mm*25mm |
|
Weight |
0.16Kg |
|
Finish |
Classic Satin/Mirror |
|
Material |
Duplex stainless steel 2205, Stainless steel 304/316 |
|
Application |
Handrail fence for various scenes, etc. |
|
Casting Process |
Silica Sol Technics with Lost-wax Process |
|
Certifications |
Australian Standard Test/Patent Certificate/IATF16949/ISO9001/ISO14001/TUV/PED/AD2000 |
|
OEM |
Available |
|
Annual Output |
2000MT |
|
Tooling Leadtime |
2--4 Weeks |
|
Delivery Time |
4--5 Weeks |
Package Specification
Plastic Bag, Bubble Bag.
Paper Carton, Wooden Case, or as Required.
Note
These adjustable vertical connectors are commonly used for stair railings, balconies, decks, and porches with square-shaped vertical balusters and handrails. They can be installed by drilling/screwing into the top tube of the railing for added joining strength.
