Spring Hinge Description
The Swimming Pool Gate Hinge is used to hang and support glass gates or doors for swimming pools where a glass panel swings open and closed using a metal tube mounted to a post or wall. The glass panel connects to the hinge on one side, while the tube inserts into the hinge mechanism on the other side. This creates a clean and modern look for your pool enclosure.
The Swimming Pool Gate Hinge offers durability, a clear view, space efficiency, a modern look, and a potential self-closing safety feature. The spring hinge itself is constructed from high-grade stainless steel, a strong and durable material that resists corrosion and rust. Typical glass thicknesses compatible with these hinges range from 8 mm to 1/2 inch (12 mm).
Spring Hinge Specifications
|
Product Name |
Spring Hinge |
|
Glass Thickness |
8-12mm |
|
Weight |
0.25Kg |
|
Finish |
Classic Satin/Mirror Powder Coat Matte Black/White PVD-Black/Gold/Rose Gold/Gun Grey Anti-conductive Black/White Transparent Satin/Mirror |
|
Material |
Duplex stainless steel 2205, Stainless steel 304/316 |
|
Application |
Glass enclosure doors, bathroom glass doors, hotels, offices |
|
Casting Process |
Silica Sol Technics with Lost-wax Process |
|
Certifications |
Australian Standard Test/Patent Certificate/IATF16949/ISO9001/ISO14001/TUV/PED/AD2000 |
|
OEM |
Available |
|
Annual Output |
2000MT |
|
Tooling Leadtime |
2--4 Weeks |
|
Delivery Time |
4--5 Weeks |
Package Specification
Plastic Bag, Bubble Bag.
Paper Carton, Wooden Case, or as Required.
Note
Remember to consider weight capacity, safety glass requirements, post or wall compatibility, and installation complexity before purchasing. Choose a hinge that can support the weight of your specific glass pool gate panel. Verify the hinge is compatible with the diameter and material of the tube you plan to use for mounting.
